Toyota Avanza 1.5
| COMPRESSOR SPECIFICATION | |
| Type | Swash Plate |
| Displacement | 116 cc/r |
| Lubricant (PAG46) | 150±10 ml |
| Direction of Rotation | CW and CCW |
| Refrigerant | R134a |
| Max Continuous Speed | 7000 rpm |
| Max Instant Speed | 8000 rpm |
| CLUTCH SPECIFICATON | |
| Voltage | DC 12 V |
| Min Engagement Voltage | 7.5 V |
| Consumption Power | 45 W |
| Max Continuous Speed | 7000 rpm |
| Max Instant Speed | 8000 rpm |
| Pulley Type | 6 PK |
| Pulley Diameter | Ø105 mm |
